Top 10 Most Asked Questions About PTFE Seals

PTFE seals—also known as Teflon® seals—are widely used across industries for their chemical resistance, wide temperature range, and low friction properties. However, many engineers, buyers, and maintenance professionals still have key questions about how, where, and why PTFE seals are the right choice for their applications. In this article, we address the top 10 most frequently asked questions about PTFE seals to help you make informed decisions and avoid costly sealing failures.
________________________________________
1. What is a PTFE seal?

A PTFE seal is a sealing component made from Polytetrafluoroethylene, a high-performance fluoropolymer known for its low friction and excellent chemical resistance. PTFE seals are used in dynamic and static applications, often in pumps, valves, rotary equipment, and hydraulic cylinders. They are especially favored in harsh environments where conventional elastomer seals may fail.
________________________________________
2. What are the advantages of PTFE seals over rubber or elastomeric seals?

•    Wider temperature range (-200°C to +260°C)
•    Superior chemical resistance to acids, solvents, and hydrocarbons
•    Low friction coefficient, reducing wear and energy loss
•    Non-stick surface, minimizing residue buildup
•    Non-aging properties, maintaining performance over time

These qualities make PTFE seals ideal for high-speed rotary shafts, cryogenic systems, and aggressive media environments.
________________________________________
3. Are all PTFE seals the same?

Not at all. PTFE seals can vary in:
•    Material composition (e.g., virgin PTFE, glass-filled, carbon-filled, bronze-filled)
•    Design (e.g., spring-energized, lip seals, backup rings)
•    Manufacturing method (e.g., compression-molded, isostatic-pressed, CNC-machined)


At Parjet, we offer customized spring-energized PTFE seals using Cantilever Springs, Helical Springs, or Canted Coil Springs—each tailored to specific operating conditions.
________________________________________
4. Do PTFE seals require lubrication?

In many applications, PTFE’s naturally low friction surface allows it to function without additional lubrication. However, in high-speed dynamic applications or when sealing against hard surfaces, light lubrication can:
•    Reduce startup friction
•    Extend seal life
•    Improve sealing efficiency
________________________________________
5. Can PTFE seals handle high pressure?

Standard PTFE seals are not inherently pressure-resistant due to their softness. But by integrating:
•    Spring energizers
•    Backup rings
•    Reinforced PTFE compounds


They can withstand pressures up to 400 bar or higher, depending on the seal design. For rotary seals under high pressure, spring-energized PTFE seals or balanced mechanical seals are recommended.
________________________________________
6. Are PTFE seals suitable for rotary or reciprocating motion?


Yes—PTFE seals excel in:
•    Rotary applications: where they reduce friction and heat buildup
•    Reciprocating applications: due to their excellent wear resistance and self-lubricating properties


The key is selecting the right spring energizer and jacket geometry. Parjet’s HiPerSeal® product line offers profiles optimized for both motion types.
________________________________________

7. How do I choose the right PTFE material for my application?

Different fillers modify PTFE’s properties:

Material selection depends on media compatibility, temperature, pressure, and motion. Parjet’s engineering team offers material consultation based on your specific needs.
________________________________________

8. Can PTFE seals be used in food, pharmaceutical, or medical applications?

Yes. Virgin PTFE is FDA-compliant, non-toxic, and non-reactive, making it ideal for:

•    Food contact seals
•    Pharmaceutical processing equipment
•    Medical gas systems

In these sectors, purity, cleanliness, and resistance to steam sterilization are key reasons for PTFE’s popularity.
________________________________________

9. Are PTFE seals reusable?

Generally, PTFE seals are not reusable. Once compressed or worn, they lose their ability to seal effectively. Reusing a PTFE seal can lead to:

•    Micro-leaks
•    Premature failure
•    Contamination (in clean applications)

It’s best to replace PTFE seals during maintenance cycles to ensure system reliability.
________________________________________

10. Why choose Parjet for PTFE seals?

Parjet is a vertically integrated PTFE seal manufacturer with:

•    Over 30 years of experience
•    In-house PTFE tube production, CNC machining, and spring design
•    Expertise in cryogenic, chemical, and high-pressure sealing
•    Custom sealing solutions with FEA-supported design and lab validation
•    Trusted by 2,100+ customers globally, with over 10 million seals produced annually

Whether you need rotary shaft seals, hydraulic seals, or spring-energized sealing solutions, Parjet offers precision, speed, and reliability—from powder to precision.
________________________________________

PTFE seals are an essential component in modern engineering, offering unmatched chemical resistance, low friction, and durability across extreme conditions. Understanding the nuances of PTFE material selection, seal design, and application requirements can dramatically increase performance and service life.


Need help selecting the right PTFE seal for your application?


Contact Parjet today—we’ll help you seal smarter.
